15 6 Inch Multi Touch Capacitive TFT LCD Module for Home Use
5.0
Shipping:
Support Sea freight
Place of Origin:
China
Payments:
L/C,D/A,D/P,T/T,Western Union,MoneyGram,OA
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Description
Product Description
CAPACITIVE TOUCH PANEL
High-performance 17.3" capacitive touch panel for demanding industrial settings.
Advanced 10-point multi-touch, 16:10 ratio, offers responsive interaction.
With ≥6H hardness & up to 8mm explosion-proof glass, it ensures clear, durable display.
Supports glove touch and water touch, ideal for factories, kiosks, marine uses.
Compatible with Windows, Android, Linux; customizable with OEM/ODM services, 1-year warranty.
USE
Factory HMI Systems
Panels for production control, CNC, and monitoring in manufacturing.
Industrial Control Rooms
Stations with multi-touch displays for system management and visualization.
Warehouse & Logistics
Terminals and systems where glove touch is crucial.
Outdoor Kiosks
Terminals exposed to sunlight, rain, and temperature variations.
Panels for production control, CNC, and monitoring in manufacturing.
Industrial Control Rooms
Stations with multi-touch displays for system management and visualization.
Warehouse & Logistics
Terminals and systems where glove touch is crucial.
Outdoor Kiosks
Terminals exposed to sunlight, rain, and temperature variations.
Product Parameters
TECHNICAL PARAMETERS | ||
Module Details | Model Number | HX1731704 |
Size | 17.3 inch | |
Operating Temperature | 0°C ~ 70°C | |
Storage Temperature | -20°C ~ 70°C | |
Outline Dimension | 403.00x240.00x14.30 mm | |
Viewing Area | 383.89x216.81 mm | |
Active Area | 381.89x214.81 mm | |
Support Systems | Windows/Android/Linux etc. | |
PCAP (Projected Capacitive) | Light Transmittance | ≥85% |
Surface Hardness | ≥6H | |
Interface Type | USB | |
Structure | Glass+Glass | |
Controller IC | ILITEK | |
Touch Points | 1-10 Points | |
Power Supply Voltage | 5V | |
TFT LCD Display | Resolution | 1920*1080 |
Interface Type | LVDS/HDMI/VGA | |
Luminance | 400 cd/m² | |
Viewing Angle | 80/80/60/80 | |
Detailed Photos
PRECISE 10-POINT MULTI-TOUCH RESPONSE
SUPERIOR GLOVE TOUCH COMPATIBILITY
Supports 10-point touch for smooth gestures like pinch-to-zoom and swipe. Ensures precision for industrial interfaces, interactive displays, and group workstations.
Supports glove touch up to 6mm thickness, enhancing safety and efficiency in various environments.
EXPLOSION-PROOF COVER GLASS
HIGH SURFACE HARDNESS
Reinforced glass up to 8mm for explosion-proof safety, protecting against impacts and damage.
Rated 6H+ for scratch resistance, maintaining appearance in demanding applications.
FAQ
Q1: Are you a factory or a trader?
A: We are a manufacturer integrating industry and trade. Welcome to visit us.
Q2: Can I add my LOGO to the product?
A: We offer customization on demand, including LOGO, color, and size adjustments.
Q3: What payment methods do you support?
A: We accept T/T, Western Union, PayPal, cash, etc. Details are negotiable.
Q4: What are your modes of transportation?
A: We select transport modes (sea, air, land) based on goods or your preferences.
Q5: How can I get an accurate quotation?
A: Send your demand info and product pictures. We'll provide a tailored solution and price.
A: We are a manufacturer integrating industry and trade. Welcome to visit us.
Q2: Can I add my LOGO to the product?
A: We offer customization on demand, including LOGO, color, and size adjustments.
Q3: What payment methods do you support?
A: We accept T/T, Western Union, PayPal, cash, etc. Details are negotiable.
Q4: What are your modes of transportation?
A: We select transport modes (sea, air, land) based on goods or your preferences.
Q5: How can I get an accurate quotation?
A: Send your demand info and product pictures. We'll provide a tailored solution and price.
