Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 1
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 2
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 3
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 4
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 5
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 6
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 7
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 1
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 2
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 3
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 4
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 5
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 6
Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 7

Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens

Inquiry

    oops...!

    no product data.

    Go to homepage
    Write a Review
    Touch Controller IC
    Cypress
    Certification
    ISO9001
    Drive IC
    Cypress
    Features
    touch with glass/gloves/water
    Width
    100.00mm
    Diagonal Screen Size
    7 inch
    Length
    165.00mm
    surface treatment
    AG+AF
    Keywords
    Touch Screen Glass Panel
    Interface
    IIC/USB
    Operating System
    XP/WIN7/WIN8/WIN10/Android/Linux
    Application
    Industrial, Industrial Application
    Touch points
    10 Points
    Structure
    Glass+Glass+FPC
    Touch type
    Projected Capacitive Multi Touch Panel
    Product name
    7 inch IIC/USB multi touch screen panel with AG+AF cover glass
    Place of Origin
    China
    Type
    Capacitive
    Custom 1.3~65 inch PCAP(projected capacitive) 7 inch IIC/USB multi touch screen panel
    with AG+AF cover glass lens
    Certifications
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 8
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 9
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 10
    Product Description
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 11
    Model Number
    HX0701603
    Surface Hardness
    ≥6H
    Size
    7.0 inch
    Operating Environment
    -20℃ ～ 70℃,≤85% RH
    Interface Type
    IIC/USB
    Storage Environment
    -30℃ ～ 80℃,≤85% RH
    Surface treatment
    AG+AF
    Power Supply Voltage
    2.8V ～ 3.3V
    Structure
    GLASS+GLASS
    Outline Dimension
    165.00x100.00x1.45mm
    Controller IC
    Cypress
    Viewing Area
    154.88(W)x86.72(H) mm
    Touch Points
    10 points
    Support Systems
    Windows/Android/Linux etc.
    Transparency
    ≥85%
    Warranty
    1 year
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 12
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 13
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 14
    Related Products
    We can provide USB controller and HDMI/VGA driver board.
    If you didn't  find the suit one, Just tell us your requirements, so i could recommended you more suitable products.Please contact us.
    Application
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 15
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 16

    Industrial Control

    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 17

    Medical Equipment

    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 18

    Intelligent Household Industry

    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 19

    Outdoor Equipment

    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 20
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 21
    Bonding(PCAP and TFT)
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 22
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 23
    1.Support Touch with glove of all materials and thickness with 6mm
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 24
    2.Support Touch with water/brine
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 25
    3.Cover glass Support -8mm thickness--explosion-proof
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 26
    4.Cover glass surface treatment--AG, AR, AF
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 27
    Anti Glare (AG) processing could eliminate screen surface mirror problem
    through converting direct light to diffuse light on the touch screen.
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 28
    Anti-Reflective(AR) processing means adding a type of coating that could reduce
    reflected light on the cover glass,which dereases screen reflection
    and increases visual effects significantly in the sun.
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 29
    Anti-Fingerprint (AF) processing is adding on the cover glass a kind of coating that could increases surface smoothness,reduces surface aliding resistance,residual water and fingerprints on the surface significantly and improves touch feeling and clarity.
    Packing & Delivery
    Custom 1.3~65 Inch Pcap(projected Capacitive) 7 Inch Iic/usb Multi Touch Screen Panel With Ag+af Cover Glass Lens 30
    FAQ

    Q:Can you provide OEM service?
    A:yes, we can provide both OEM and ODM service,can customize products according to the drawings you supply.
    Q: How can I trust your product quality?
    A:We have more than 10 years experience in touch screen industry.  From material purchasing to product delivery, we have own professional staff and procedures to prevent potential quality risk. Our products have been approved by ROHS.
    Q: What's your after-sale service?
    A: If any problems, you will get our reply within 24 hours. Solution will be offered instantly by our professional and strong technical team.
    Q:What is the minimum order?
    A:our company mainly deals with wholesale deals,but if you insist buying one set,welcome to take a sample for you check quality and function.
    once sample is confirmed, we could allow for a small mount of orders(no quantity limitation) to be put into production and once this is confirmed, MOQ is required.
    Q:How long is the warranty time for your products?
    A:Normally 1 year warranty without damaged by people actions like misuse.It depends on different products.
